Basic conditions and steps for installing and cleaning oil storage tanks at skid-mounted gas stations

We all know that the core component of a skid-mounted gas station is the oil storage tank. When installing and cleaning, it is necessary to conduct on-site inspections in advance to see whether the on-site environment meets the conditions for construction and cleaning. After all, the safety requirements for oil storage tanks are very high. Let's analyze the basic conditions and steps for installing and cleaning oil storage tanks at skid-mounted gas stations.

Six basic conditions for installing and cleaning oil tanks at skid-mounted gas stations

Among the components of skid-mounted gas stations, oil tanks are used as tools for storing oil products. Basically, they are rarely moved after installation. However, sometimes we have to do necessary cleaning work on the oil tanks. Today we will introduce the six basic conditions for cleaning oil tanks at skid-mounted gas stations.

1. The oil tank leaks or is otherwise damaged.

2. When the oil tanks of mobile skid-mounted gas stations are replaced with different oil products, the remaining oil products in the tanks should not be mixed with the newly loaded oil products to prevent the purity of the oil from being affected or the low-quality oil products from being put into production, causing safety hazards.

3. When the oil tanks of mobile skid-mounted gas stations need to be inspected or repaired with fire, they need to be cleaned for welding, dismantling and cutting to prevent the residual gas in the oil tank from burning when encountering the open flame during operation.

4. Newly built and rebuilt oil tanks need to be cleaned and dried before filling with oil, and the debris in the tank needs to be removed.

5. When the oil tanks store oil for a certain period of time (light oil, heavy diesel oil, lubricating oil, oil tanks shall not exceed 3 to 5 years), if it is found that the bottom of the oil tank contains water and many impurities, which affects the quality of the oil products, it should be cleaned at any time.

6. When the oil tanks are filled with oil for a long time, the oil tanks are relatively dirty and need to be thoroughly cleaned and maintained.

If the above six conditions are met, the oil tanks of the skid-mounted gas station must be cleaned, otherwise there will be safety and quality risks.

Six basic steps to install oil storage tanks at skid-mounted gas stations

We all know that oil tanks are the main components of skid-mounted gas stations. When installing, the oil tanks and the tanks of skid-mounted gas stations are carried out separately. Installing oil tanks is the top priority of the entire skid-mounted gas station installation. Today we will look at the six basic steps to install oil tanks at skid-mounted gas stations.

1. Earth excavation and foundation pit tamping.

2. Reinforced concrete and masonry engineering, mobile skid-mounted gas stations;

3. Earth backfilling, mechanical tamping, backfill soil layer greater than 500mm;

4. Use medium and coarse sand for the sand cushion layer, lay a thickness of 200~250mm, and use a flat vibrator to sprinkle water and tamp.

5. Asphalt sand cushion layer, medium and coarse sand and No. 60 road petroleum asphalt are heated to make asphalt sand, which is laid flat in layers and blocks. The thickness is 80~100mm, and the slope of the top surface of the tank foundation from the center to the surrounding is 0.015~0.035

6. Slope protection construction, the slope protection is carried out after the tank is subjected to water pressure test, and the slope protection width is 800~1000mm. Asphalt mastic is used to fill the slope protection and the bottom plate of the tank, Xi'an skid-mounted gas station.

The above six points are the basic methods and steps for installing oil tanks in skid-mounted gas stations. I hope it will be helpful to everyone. Tai'an Shengding Metal Container Manufacturing Co., Ltd. mainly produces explosion-proof barrier skid-mounted equipment, explosion-proof barrier materials, oil tanks, oil storage tanks, horizontal oil tanks, vertical oil tanks, acid and alkali tanks, water treatment equipment, container heads, boiler auxiliary machines and other types of metal containers. If you have any inquiries, please call: 13953895568
