Three major points to note when installing and fixing double-layer oil tanks at skid-mounted gas station

Among the various components of the skid-mounted gas station, the double-layer oil tank is the core component. Its installation and fixation has always been an important part of the construction of the skid-mounted gas station. Today we will explain to you the three major precautions for the installation and fixation of the double-layer oil tank.

1. After the double-layer oil tank is hoisted and placed on the cement pillow, check whether there is a gap between the cement pillow and the oil tank. If there is a gap, use a rubber pad to fill it to ensure that the force of the oil tank is uniform.

2. After the skid-mounted refueling inspection is qualified, a 10mm rubber shock-absorbing pad is laid on the cement pillow, and then the hoisting personnel will hoist it. The hoisting process must strictly abide by the operating procedures to ensure the safety of equipment and personnel and move the skid-mounted gas station.

3. Before installing the skid-mounted refueling tank, check the curvature of the cement pillow, the center line, and whether the levels of the three cement pillows are consistent. The center line is plus or minus 5mm, the anchor bolts are exposed to the concrete by no less than 100mm, and the cement pillow particles are less than 3mm. After the oil tank is installed in place, it is fixed with fixed straps and embedded bolts. To prevent the straps from damaging the tank body, a layer of 5mm rubber pads must be added to the inner surface of the straps. When tightening the straps, both sides must be tightened at the same time to avoid local force damage to the tank body. The company's convenient gas station. The pre-buried oil tank must be made of high-quality yellow sand, without large particles of stones and hard debris, and sea sand and acidic substances cannot be used for filling. Water must be poured once every 300mm of yellow sand to ensure that there is no gap in the yellow sand. The above are the three major precautions for the installation and fixation of double-layer oil tanks in skid-mounted gas stations. The installation work requirements of skid-mounted gas station are strict. We must follow the installation steps and remember not to lose the big because of the small.
